| Manufacturer | OMRON |
| Type of relay | electromagnetic |
| Contacts configuration | DPDT |
| Rated coil voltage | 24V DC |
| AC contacts rating @R (at resistance load) | 5 A / 250 VAC |
| DC contacts rating @R (at resistance load) | 5 A / 30 VDC |
| Contact current max. | 5A |
| Switched voltage | max 380V AC, max 125V DC |
| Relay variant | miniature |
| Mounting | PCB |
| Coil resistance | 1.1kΩ |
| Operate time | 15ms |
| Body dimensions | 29 x 13 x 25.5mm |
| Release time | 5ms |
| Operating temperature | -40...70°C |
| Relay series | G2R |
| Contact resistance | 50mΩ |
| Terminal pitch | 5mm |
| Coil current | 21.8mA |
| Enclosure description | standard seal |
| Leads | for PCB |
| Related items | PODST-3 |
| Packaging | 100pc/tray |
Note: all the descriptions and prices are subject to change without prior notice.
Free Shipping: No
Shipping Weight/Unit(g): 20.00
Std. Packing Qty. (pcs): 100
