Features:
Easy to assembly
Supplied with 16A 4-pole Terminal Block
Flame Retardant UL94L-0 Housing
Spec.:
Material Housing: PA66, UL94V-0
Wire guard: Stainless steel
Contact: Copper
The electrical parameters
Rated voltage: 450V
Rated current: 16 A
Contact resistance: 20 mΩ
Insulation resistance:5000MΩ/DC1000V
Withstanding voltage : AC2500V/1 min
Wire range: 22-14 AWG, 0.75-2.5mm⊃2;
Ambient temperature : -40°C~+105°C
Strip length : 7-7.5 mm
Pitch :10.0mm
Poles:4P
Datasheet:
Fast Connection Terminal Block For Lighting Fixtures With Junction Box - Datasheet.pdf
Note: all the descriptions and prices are subject to change without prior notice.
Free Shipping: No
Shipping Weight/Unit(g): 0.00
Std. Packing Qty. (pcs): 100
