Features:
The UHF Female connector is used to connect UHF Male device.
Compatible with antenna switch, OR.
Widely used for CB radios, public address systems, audio, video, mobile
radio, and test equipment, antennas, broadcast, Wi-Fi, telecom, coaxial
cable.
Specifications:
Materials: brass & nickel plated
Impedance: 50 ohm, Low-loss
Frequency Range: 0-300MHz
Working Voltage: 1000V r.m.s at sea level
Withstanding Voltage: 2500V r.m.s at sea level
Insulation resistance: ≥5000MΩ
Center Conductor retention force: ≥0.56N
Durability: ≥500times(cycles)
Insulators: PTFE
VSWR: ≤1.15
Temperature Range: -55~+155℃
Note: all the descriptions and prices are subject to change without prior notice.
Free Shipping: No
Shipping Weight/Unit(g): 17.20
Std. Packing Qty. (pcs): 50
